1986 - Page 9


Babbington (Cinderhill) Closed After 142 Years
- Continued -


A Sherwen feeder was installed in 1960 and a new stockyard operational also in 1960.

The old Newcastle coal wharf was abandoned in 1962.

A new coal prep plant was opened in 1963.

A Disc shearer with Walton chocks and Groetschel bars with Dobson hydraulic props began production in 1963.

In 1964 on the surface there was a diesel shunting engine named Jayne.

A 200hp Wild haulage engine was installed in 1965.

An experimental movable shotfiring cabin on wheels was in use by 1972.

A Waffler cutter was installed in 1973.

By 1976 there was a standby fan at No7 shaft.

A surface drift started in the pit yard dipping at 1in3 was stopped before reaching any seam but an abandoned plan was never sent in. It only came to light when I was checking over information when work was being done following abandonment of the mine. A footbridge over the lines was built in 1984.

Thirling Teams

Successful Thirling As Men From Babbington Met Men From Hucknall

Babbington was connected to Hucknall in 1985 and the 2 collieries merged and coal from the Babbington workings was transported through the connection road and raised at Hucknall and included in Hucknall output. The photo shows the successful thirling as men from Babbington met men from Hucknall.

Water collected at Babbington after being pumped to the surface at around 600 gallons per minute from other neighbouring collieries was then allowed to flow through to Moorgreen and into Bentinck via the borehole connection as described in Bentinck résumé.

Maximum output was 881,134 tons in 1967/68 with 1,423 men and maximum manpower was 1,829 in 1955.

Manpower: Cinderhill, (T North and Co) 1842-1867, (John W Wright) 1867-1871, (Chas Seely and Co) 1871-1887, (Babbington Colliery Co) 1887-1936.

  • 1894: 632 Top Hard, 281 s/f, total 913 men
  • 1895 926 men
  • 1900: Cinderhill 497, Babbington 939, total 1,436 men
  • 1903: 1,469 men
  • 1905: 1,500 men
  • 1911: 1,486 men
  • 1913: 1,275 men
  • 1920: 1,740 men
  • 1923: 1,682 men
  • 1925: 1,632 men
  • 1926: 1,416 men
  • 1927: 1,388 men
  • 1928: 1,314 men
  • 1929: 1,016 men
  • 1930: 774 men
  • 1933: 836 men
  • 1935: 941 men
  • (BA Collieries Ltd 1936-46)
  • 1940: 1,205 men
  • 1945: 1,844 men.

Tonnage and Manpower NCB: No6 Area EMD: 1947: 536,211 tons, 1,821 men

  • 1948: 637,936 tons, 1,978 ave, max 2,025 men
  • 1949: 700,562 tons, 1,913 men
  • 1950: 746,002 tons, 1,774 men
  • 1951: 782,623 tons, 1,833 men
  • 1952: 714,772 tons, 1,930 men
  • 1953: 667,190 tons, 1,901 men
  • 1954: 730,158 tons, 1,879 men
  • 1955: 697,878 tons, 1,861 men
  • 1956: 676,222 tons, 1,764 men
  • 1957: 624,471 tons, 1,812 men
  • 1958: 639,671 tons, 1,764 men
  • 1959: 726,630 tons, 1,608 men
  • 1960: 703,389 tons, 1,496 men
  • 1961: 718,252 tons, 1,453 men
  • 1962: 778,429 tons, 1,420 men
  • 1963: 792,805 tons, 1,394 men
  • 1963/64: 779,261 tons, 1,395 men
  • 1964/65: 761,232 tons, 1,375 men
  • 1965/66: 816,681 tons, 1,363 men
  • 1966/67: 747,437 tons, 1,365 men

South Nottinghamshire Area: 1967/68: 864,021 tons (max), 1,423 men

  • 1968/69: 828,240 tons, 1,364 men
  • 1969/70: 727,395 tons, 1,349 men
  • 1970/71: 724,773 tons, 1,318 men
  • 1971/72: 541,139 tons, 1,315 men
  • 1972/73: 632,386 tons, 1,256 men
  • 1973/74: 500,931 tons, 1,242 men
  • 1974/75: 710,300 tons, 1,245 men
  • 1975/76: 573,076 tons, 1,222 men
  • 1976/77: 580,171 tons, 1,175 men
  • 1977/78: 584,095 tonnes, (574,868 tons), 1,185 men
  • 1978/79: 640,104 tonnes, 1,154 men
  • 1979/80: 595,281 tonnes, 1,150 men
  • 1980/81: 556,456 tonnes, 1,121 men
  • 1981/82: 501,115 tonnes, 1,097 men
  • 1982/83: 643,142 tonnes, 1,083 men
  • 1983/84: 480,926 tonnes, 988 men
  • 1984/85: 357,790 tonnes, 732 men

British Coal:
1985/86: 261,350 tonnes, 471 men. Output for Babbington, was for 9 months only, Apr – Dec 1985. Coal produced afterwards is included in Hucknall output.
Colliery closed 31st October 1986. Reserves allocated to Hucknall.

Agents:

  • John Thomas Woodhouse (consulting engineer)
  • Stephen Barton replaced 1842
  • Richard Gresham Barber (resident engineer) 1842-
  • George C Fowler and Agent for Chas Seely and Co pre 1883-1886, cont’d for Babbington Coal Co 1897-1910 and Agent 1911-1921
  • Tom A Lawton (1161) Agent 1922-1936
  • Major FMT Bunney (2760) Agent 1936-1939
  • Alan Hill (2769) Agent 1940-1941
  • Peter L Collinson (1331) Agent 1941-1943
  • Major FMT Bunney (2760) Agent 1945-1950
  • Harold Taylor (2108) Agent 1950-1952 (later Area General Manager).

Sub-Area Managers / Group Managers:

  • Mike H Young (…) Sub-Area Manager 1952-1956
  • John K Walker (4319) Group Manager 1956-1966

Managers for Cinderhill and Babbington:

  • William Hunt (1686) (Babbington) 1899-1900
  • John Poxon (996) Babbington) 1901-1910
  • EF Treece (1609) Cinderhill) 1911-1930
  • John Poxon (996) Manager for both 1930-1931
  • Edwin W Lane (856) 1931-1935 (later Production Manager No3 Area)
  • Alan Hill (2769) 1936-1938
  • C Knowles (2503) 1938-1940
  • Harry Blakemore Bennett (2820) 1940-1944 (promoted to Sub Area Manager S Derbys, later Area General Manager No4 Area, Huthwaite)
  • Major FMT Bunney (2760) Manager and Agent 1944-1945 (later General Manager in NW), Harold Taylor (2108) Manager 1945-1949
  • Harold Horrocks (3707) 1949-1956
  • Stan Chadwick (3747) 1956-1959 (promoted to Group Manager)
  • J Derek Harding (5225) 1959-1967 Agent Manager (left industry to a firm manufacturing hoses)
  • David Andrew Weir (6148) 1967-1972 Agent Manager (transferred to Moor Green)
  • Arthur Townsend (6400) 1972-1975 Agent Manager (transferred to Cotgrave)
  • Albert Knight (7873) General Manager 1976-1986.

Deputy Managers:

  • William Housley (2nd) 1963-1968
  • Arthur Ball (6178) 1969-1972
  • W Vic Brown (9249) 1972-1973 (promoted from Ollerton, transferred to Pye Hill, later Manager New Hucknall, Annesley and Moorgreen)
  • ....
  • Edward Jack Fletcher (6076) 1977-1982 (promoted from Assistant Manager)
  • Graham Coupe (8911) 1983-1984 (promoted from Assistant Manager, transferred to Hucknall, later Manager Hucknall then Ollerton, resigned) (d 2013)
  • John Payne (9235) 1984-1987 (transferred from Hucknall, promoted to Manager Linby, later Newstead then Closed Collieries Manager based at Mansfield) 1988-1990.

Assistant Managers:

  • SE Marston (2nd) 1950-
  • William H John (Sen) (3711) 1956-
  • Edward Jack Fletcher (6076) 1976-1977 (promoted to Deputy Manager)
  • Graham Coupe (8911) 1978-1983 (promoted to Deputy Manager).

Undermanagers for Cinderhill and Babbington:

  • .... Samuel Walters Underviewer (in post at 1856)
  • John Smith (2nd) (Cinderhill) pre 1887-1895
  • Sam Kirk (2nd) 1895-1897
  • S Starr (Babbington) 1897-1903
  • JH Eley (Babbington) 1904-1907
  • TK Knox (2nd) (Babbington) 1908-1909
  • William Poxon (3497) Babbington) 1909-1915
  • G Starr (2nd) (Cinderhill No4) 1921-1930
  • G Housley (2nd) (Babbington) 1915-1930, for both 1931-1937 and (Babbington) 1938-
  • AJ Wilkinson (2nd) (Babbington) 1937-1938
  • Harry B Bennett (2820) (Cinderhill No4) 1938-1940 (from Lancs, promoted to Manager)
  • JW Criddle (1317) (Babbington or Cinderhill No1) 1940-1941
  • FTP Dickens (3219) (No1) 1941-1942
  • SE Marston (2nd) (Cinderhill No4) 1940-1941, (Cinderhill No1) 1942-1949
  • Russell Bracegirdle (3202) (No4) 1942-1943
  • Harold Horrocks (5043) (No4) 1943-
  • Len C Hogg (3275) (No1) 1944-1947 and (No4) 1947-1949 (promoted to Manager Bestwood)
  • W Clements (2nd) (No1) 1947-
  • William Housley (2nd) 1949-1963
  • G Walters (2nd)
  • Edward J Fletcher (6076) 1963- (promoted to Assistant Manager)
  • G Toplis (7577) 1966-1969
  • John Proudlock (9159) 1968-1969
  • Graham Coupe (8911) 1969-1978 (promoted to Assistant Manager)
  • Alan Hardy (10653) 1976-1985
  • Howard G Awbury (10648) 1978-1982 (promoted to Deputy Manager and then Manager Bentinck)
  • Mick D Orchiston (11282) 1983-1984 (transferred to Calverton, later Manager Calverton, Ollerton, Daw Mill, left)
  • Paul W Grimshaw (10995) 1984-1986 (transferred to Surface Superintendent Mansfield at closure, later a Roof-bolting Engineer).
  • Horace Berrisford U/m at Cinderhill ...date?

Assistant Undermanagers included:

  • John Proudlock (9159) (from Langley Park in North East, left to outside industry), returned to NCB later.

Technical Assistants included

  • A John Wardle (9360) 1966 (transferred from New Hucknall, previously Ventilation Officer Selston 1961, transferred to Annesley, later Manager Annesley, Bentinck, Production Manager, finally a Director).

Surveyors included:

  • John Thomas Walters (1st class cert, endorsed for surveying by Divisional Inspector of Mines) -1927
  • Robert Scott (to Allerton)
  • Lewis H Spencer (517) (later Area Chief) -1946
  • Ted Reeve 1947
  • Arthur Walmsley (... ) -1950
  • Ron Sheldon (2305) (ex Fleet Air Arm pilot, 1950-1958, to HQ then Deputy and Area Chief South Nottinghamshire), Ray S Holmes (3981) (transferred from Wollaton) 1958-1985
  • Anthony (Tony) R Barnes (5990) (from Bentinck, promoted from Deputy 1985 transferred to Hucknall on merger 1st Jan 1986, then appointed Senior Surveyor, Nottinghamshire Area Oct 1986, later appointed Deputy Nottinghamshire Group 1990 and then Surveyor and Minerals Management Engineer 1992-1993 then including Planning and Geology -1994).
